The device has excellent detection, identification, interference, jamming and long-distance working capabilities. It does not require supervision and automatically detects and counte- racts drones, letting them to hover, land or return. It prevents drones from entering the de- fense zone and protects the safety of low-altitude airspace.
13 Frequency Bands & 4 Directional Jamming Arrays Super Interference toFPV Drones
1+N Flexible Deployment
FPV Video Transmission Detection and Capture
360° Full Frequency Band Detection
Full Frequency Band Detection
FPV Video Transmission Jamming
Multiple jamming Modes
1+N Equipment Interlinking
Super Interference to FPV Drones
FPV Video Transmission Signal Capture
Detection frequency band | 70MHz-6GHz full-frequency scanning, detection and display |
Detection range | ≥10km(depends on working conditions) |
FPV Video transmission detection | 500MHz-6GHz full-frequency scanning and display |
Video transmission detection range | ≥1.5km(supports viewing real-time video) |
Azimuth range | Horizontal: 360° Vertical:-90°-90° |
Detection response time | ≤10s |
Omnidirectional jamming | 420MHz-480MHz, 650MHz-730MHz, 740MHz-840MHz, 860MHz-930MHz, frequency band |
1080MHz-1200MHz, 1200MHz-1340MHz, 1340MHz-1500MHz, 1560MHz-1620MHz, 4880MHz-5080MHz, 5870MHz-6060MHz, 5100MHz-5300MHz, 5720MHz-5860MHz, 2385MHz-2490MHz (customizable) | |
Directional jamming frequency band | 850MHz-950MHz, 2385MHz-2490MHz, 5720MHz-5860MHz, 5100MHz-5300MHz |
Jamming distance | ≥3km (depends on working conditions) |
Operation temperature | (-40°C∼+60°C)±2°C |
Weight | ≤150kg |
Size | 1000mm2400mm (diameterheight) |
*
*
