Enhanced Night Vision
1080P/1500TVL Clarity
Compact Drone-Friendly Build
5V-30V Wide Voltage
Built-in IR Lights
Anti-Interference Design
1080P Sharpness
| Parameter | Specification |
| Image Sensor | 1/3" CMOS (night vision-optimized) |
| Resolution | 1500TVL (horizontal) / 1080P@30fps (video) |
| Lens | 2.1mm fixed lens, F1.8 large aperture (enhances low-light intake) |
| Night Vision | Built-in 4pcs 850nm IR LEDs; 50-100m effective night vision range (varies by light) |
| Field of View (FOV) | 120°- 130° (diagonal, wide coverage for FPV) |
| Signal System | PAL/NTSC (OSD-adjustable) |
| Minimum Illumination | 0.0001 lux (starlight level, works in near-total darkness) |
| Anti-Interference | Integrated anti-signal noise design; supports 5.8GHz FPV transmission stability |
| Image Enhancement | 3DNR (3D Digital Noise Reduction), D-WDR (Digital Wide Dynamic Range) |
| Power Supply | DC 5V - 30V (wide voltage, compatible with most drone/RC power systems) |
| Dimensions | 20mm × 20mm × 22mm (compact, drone-frame-friendly) |
| Net Weight | 8.5g (lightweight, no extra load for small drones) |
| Interface Type | Solder-pad (for power, video output, OSD control) |
| Operating Temperature | -20°C to 60°C (adapts to outdoor low/high-temperature environments) |
| OSD Functions | Brightness, IR light on/off, video format, noise reduction level adjustment |
| Day/Night Mode | Auto (light sensor-triggered) / Manual (OSD-controlled) |
*
*
